Q1273-60071 Scan Axis / X-Axis Carriage Drive Motor Assembly for HP DesignJet 4000 DesignJet 4500 DesignJet Z6100 Plotters OEM NEW
Q1273-60071 is a New Genuine OEM HP Scan-axis or X-axis motor assembly. Used to drive the carriage belt, the long toothed belt, to move the carriage from end to end of the plotter over the paper.
For 42-inch plotters (RoHS: Modified)
Scan axis motor is usually the cause of these error codes:
DesignJet 4000 system error 42:03, 42:10, related to 72:03, 86:01, 86:03, 86:10,
DesignJet 4500 / 4520 PWM Shutdown, Energy Shutdown, 42:03, 42:10, 73:03, 86:01, 86:10,
DesignJet Z6100 PWM Shutdown, Energy Shutdown, 42:03, 42:10, 73:03, 86:01,
Scan Axis motor used in the following HP DesignJet Plotter Models
Designjet 4000 Printer Q1273A, Q1273AR
Designjet 4000ps Printer Q1274A, Q1274AR
Designjet 4020 42-in Printer CM765A, CM765AR,
Designjet 4020ps 42-in Printer CM766A, CM766AR,
DESIGNJET 4500 PRINTER Q1271A, Q1271AR
DESIGNJET 4500MFP Q1276A, Q1276AR
DESIGNJET 4500PS PRINTER Q1272A, Q1272AR
Designjet 4520 42-in Printer CM767A, CM767AR,
Designjet 4520 HD Multifunction Printer CM769A, CM769AR,
Designjet 4520ps 42-in Printer CM768A, CM768AR,
DESIGNJET 4520 SCANNER CM770AR
DESIGNJET L25500 42-IN PRINTER
DESIGNJET L25500 60-IN PRINTER
Designjet Z6100 42-in Photo Printer Q6651A, Q6651AR
Designjet Z6100 42-in Printer Q6651C, Q6651CR
Designjet Z6100ps 42-in Photo Printer Q6653A, Q6653AR
DESIGNJET Z6100PS 42-IN PRINTER Q6653C, Q6653CR
DesignJet 4000 refer to page 8-88 in the service manual for remove and replace instructions.
DesignJet 4500 / 4520 refer to page 8-95 in the service manual for remove and replace instructions.
DesignJet Z6100 refer to page 346 (chap. 8) in the service manual for remove and replace instructions.
